Metering
Automation Math Variable Metering
Automation Math Variable Metering
Use the MET AMV command to display all 256 AMV values, as shown in Figure 7.9.
MIRRORED BITS Remote Analog Metering
Use the MET ANA command to display the analog values used with MIRRORED
B
ITS communications, as shown in Table 7.5.
=>>MET AMV <Enter>
Relay 1 Date: 04/07/2008 Time: 21:04:33.579
Station A Serial Number: 2008030645
Automation Analog Quantities
AMV001 = 0.000 AMV002 = 0.000 AMV003 = 0.000
AMV004 = 0.000 AMV005 = 0.000 AMV006 = 0.000
AMV007 = 0.000 AMV008 = 0.000 AMV009 = 0.000
AMV010 = 0.000 AMV011 = 0.000 AMV012 = 0.000
AMV013 = 0.000 AMV014 = 0.000 AMV015 = 0.000
.
.
.
AMV238 = 0.000 AMV239 = 0.000 AMV240 = 0.000
AMV241 = 0.000 AMV242 = 0.000 AMV243 = 0.000
AMV244 = 0.000 AMV245 = 0.000 AMV246 = 0.000
AMV247 = 0.000 AMV248 = 0.000 AMV249 = 0.000
AMV250 = 0.000 AMV251 = 0.000 AMV252 = 0.000
AMV253 = 0.000 AMV254 = 0.000 AMV255 = 0.000
AMV256 = 0.000
=>>
Figure 7.9 AMV Report
Table 7.5 Information Available With the MET ANA Command
Command Information
MET ANA Analog value in channel A
Analog value in channel B
