Settings
Port Settings
Make Table 12.9 settings on the Ethernet port (Port 5).
NOTE: SEL advises against enabling
anonymous FTP logins (FTPANMS = Y)
except under test conditions. The
Ethernet card does not require a
password for the special FTP user
name “anonymous”. If you enable
anonymous FTP logins, you are
allowing unrestricted access to the
SEL-400 series relay and host files.
FMRHIS Enable History Region for Fast Message Access (Y/N) N
FMRBRKR Enable Breaker Region for Fast Message Access (Y/N) N
FMRSTAT Enable Status Region for Fast Message Access (Y/N) N
FMRANA Enable Analog Region for Fast Message Access (Y/N) Y
Table 12.9 IP Configuration
Label Prompt Default Value
IPADDR Device IP Address / CIDR Prefix (w.x.y.z/t) 192.168.1.2/24
DEFRTR Default router (w.x.y.z) 192.168.1.1
ETCPKA Enable TCP Keep-Alive (Y,N) Y
KAIDLE TCP Keep-Alive Idle Range (1–20 seconds) 10
KAINTV TCP Keep-Alive Interval Range (1–20 seconds) 1
KACNT TCP Keep-Alive Count Range (1–20) 6
BUSMODE
a
a
Available on devices with IEC 61850 Sampled Values (SV) publication or subscription capability.
Bus Operating Mode (INDEPEND, MERGED) INDEPEND
NETMODE Operating Mode (FIXED, FAILOVER, SWITCHED, PRP...) FAILOVER
NETPORT Primary Network Port (A, B, C, D)
b
b
The specific options available depend on the physical ports installed in the hardware.
C
PRPTOUT PRP Entry Timeout (100–10000 milliseconds) 500
PRPINTV PRP Supervision TX Interval (1–10 seconds) 2
PRPADDR PRP Destination Addr LSB (0–255) 0
FTIME Failover Time-Out (0–65535 milliseconds) 5
NETASPD
c
c
This setting applies only if the port is installed and it is a twisted-pair port (10/100BASE-T).
Port 5A Speed (Auto, 10, 100) Auto
NETBSDP
c
Port 5B Speed (Auto, 10, 100) Auto
NETCSPD
c
Port 5C Speed (Auto, 10, 100) Auto
NETDSPD
c
Port 5D Speed (Auto, 10, 100) Auto
Table 12.8 Fast Message Read Data Access (Sheet 2 of 2)
Label Prompt Default Value
Table 12.10 FTP Configuration
Label Prompt Default
FTPSERV
a
a
If you change these settings and accept the new settings, the Ethernet card closes all active
network connections and briefly pauses network operation.
Enable FTP Server (Y, N) N
FTPCBAN FTP Connect Banner FTP SERVER:
FTPIDLE
a
Idle Time-Out (5–255 minutes) 5
FTPANMS
a
Enable Anonymous FTP login (Y, N) N
FTPAUSR Anonymous User Access Level 0
