12.9
Date Code 20171006 Instruction Manual SEL-400 Series Relays
Settings
Port Settings
Make the Table 12.14 settings in relays that support IEC 61850-9-2 Sampled Val-
ues (SV) subscriptions.
Make Table 12.15 settings in relays that support IEC 61850-9-2 SV publications.
Table 12.11 HTTP Server Configuration
Label Prompt Default Value
EHTTP Enable HTTP Server (Y,N) N
HTTPPOR HTTP Port Number (1–65534) 80
HIDLE HTTP Session Idle Timeout in minutes (1–30) 5
Table 12.12 Telnet Settings
Label Prompt Default
ETELNET Enable Telnet (Y, N) N
TCBAN Telnet Connect Banner TERMINAL SERVER:
TPORT
a
a
If you change these settings and accept the new settings, the relay closes all active network
connections and briefly pauses network operation.
Telnet Port (23, 1025–65534) 23
TIDLE Telnet Port Time-Out (1–30 minutes) 15
Table 12.13 IEC 61850 Configuration
Label Prompt Default
E61850 Enable IEC 61850 Protocol (Y, N) N
EGSE
a
a
Settings EGSE and EMMSFS are hidden when E61850 is set to N.
Enable IEC 61850 GSE (Y, N) N
EMMSFS
a
Enable MMS File Services (Y, N) N
Table 12.14 SV Receiver Configuration
Label Prompt Default Value
SVRXEN Enable SV Reception (Number of streams 0–7) 0
SVRADRs
a
a
s represents the subscription number. Seven subscriptions are supported. Only settings for
subscriptions enabled by SVRXEN will be visible.
SV Stream s Subscribed MAC Address
b
b
Layer 2 multicast address only. Broadcast address is not allowed.
01-0C-CD-04-00-0s
RAPPIDs
a
SV Stream s Rx APPID (0x4000–0x7FFF)
c
c
The 0x prefix is used to indicate that this setting is in hexadecimal.
0x4000
SVRsICH
a
SVRXs Channel Current Terminal (OFF,W,X) W
SVRsVCH
a
SVRXs Channel Voltage Terminal (OFF,Y,Z) Y
Table 12.15 SV Transmitter Configuration (Sheet 1 of 2)
Label Prompt Default Value
SVTXEN Enable SV Transmission (Number of streams 0–7) 0
SVTADRp
a
SVT p Destination MAC Address
b
01-0C-CD-04-00-0p
TAPPIDp
a
SV Stream p Tx APPID (0x4000–0x7FFF)
c
0x4000
TSVIDp
a
SVID p (String of 63 characters a–z,A–Z,_,0–9) "4000"
TVLANp
a
SV p Transmit VLAN ID (0x000–0xFFF)
c
0x000
TPRIOp
a
SV p Transmit VLAN Priority (0–7) 4
