SEL-400 Series Relays Instruction Manual Date Code 20171006
Settings
Port Settings
Make Table 12.16 settings if Port setting PROTO := DNP.
SVTpICH
a
SVTXp Channel Current Terminal (W,X) W
SVTpVCH
a
SVTXp Channel Voltage Terminal ([range]) Y
a
p
represents the publication number. Seven publications are supported. Only settings for
publications enabled by SVTXEN will be visible.
b
Layer 2 multicast address only. Broadcast address is not allowed.
c
The 0x prefix is used to indicate that this setting is in hexadecimal.
Table 12.16 DNP3 Serial Protocol Settings (Sheet 1 of 2)
Label Prompt Default Value
DNPADR DNP Address (0–65519) 0
DNPID DNP ID for Object 0, Var 246 (20 characters) “Relay 1-DNP”
DNPMAP DNP Session Map (1–5) 1
ECLASSB Class for Binary Event Data (OFF, 1–3) 1
ECLASSC Class for Counter Event Data (OFF, 1–3) OFF
ECLASSA Class for Analog Event Data (OFF, 1–3) 2
ECLASSV Class for Virtual Terminal Data (OFF, 1–3) OFF
TIMERQ Time-Set Request Interval (I, M, 1–32767 minutes) I
DECPLA Currents Scaling (0–3 decimal places) 1
DECPLV Voltages Scaling (0–3 decimal places) 1
DECPLM Misc Data Scaling (0–3 decimal places) 1
STIMEO Select/Operate Time-Out (0.0–60.0 seconds) 1.0
DRETRY Data Link Retries (OFF, 1–15) OFF
DTIMEO Data Link Time-Out (0.0–30.0 seconds) 1
MINDLY Minimum Delay from DCD to TX (0.00–1.00 seconds) 0.05
MAXDLY Maximum Delay from DCD to TX (0.00–1.00 seconds) 0.10
PREDLY Settle Time-RTS On to TX (OFF, 0.00–30.00 seconds) 0.00
PSTDLY Settle Time-TX to RTS Off (0.00–30.00 seconds) 0.00
DNPCL Enable Control Operations (Y, N) N
AIVAR Default Variation for Analog Inputs (1–6) 2
ANADBA Analog Reporting Deadband for Currents (0–32767) 100
ANADBV Analog Reporting Deadband for Voltages (0–32767) 100
ANADBM Analog Reporting Deadband (0–32767) 100
ETIMEO Event Message Confirm Time-Out (1–50 seconds) 2
UNSOL Enable Unsolicited Reporting (Y, N) N
PUNSOL Enable Unsolicited Reporting at Power-Up (Y, N) N
REPADR DNP Address to Report to (0–65519) 1
NUMEVE Number of Events to Transmit On (1–200) 10
AGEEVE Age of Oldest Event to Transmit On (0–99999) 2
URETRY Unsolicited Message Max Retry Attempts (2–10) 3
UTIMEO Unsolicited Message Offline Time-Out (OFF, 1–5000 sec) 60
EVEMOD Event Mode (SINGLE, MULTI) SINGLE
