Settings
Port Settings
Make Table 12.17 settings if configuring DNP3 LAN/WAN.
MODEM Modem Connected to Port (Y, N) N
MSTR Modem Startup String (30 chars max) “E0X0&D0S0=4”
PH_NUM1 Phone Number for Dial-Out (30 chars max) “”
PH_NUM2 Backup Phone Number for Dial-Out (30 chars max) “”
RETRY1 Retry Attempts for Phone 1 Dial-Out (1–20) 5
RETRY2 Retry Attempts for Phone 2 Dial-Out (1–20) 5
MDTIME Time to Attempt Dial (5–300 seconds) 60
MDRET Time Between Dial-Out Attempts (5–3600 seconds) 120
Table 12.17 DNP3 LAN/WAN Settings (Sheet 1 of 2)
Label Prompt Default Value
EDNP Enable DNP Sessions (0–6) 0
DNPADR DNP Address (0–65519) 0
DNPPNUM DNP TCP and UDP Port (1025–65534) 20000
DNPID DNP ID for Object 0, Var 246 (20 characters) “RELAY1-DNP”
Ethernet DNP3 Master n Configuration, n = 1 to value of EDNP, max 6
a
DNPIPn IP Address (w.x.y.z) 192.168.1.[100+n]
DNPTRn Transport Protocol (UDP, TCP) TCP
DNPUDPn
b
UDP Response Port (REQ, 1025–65534) 20000
DNPMAPn DNP Session Map (1–5) 1
CLASSBn Class for Binary Event Data (OFF,1–3) 1
CLASSCn Class for Counter Event Data (OFF,1–3) OFF
CLASSAn Class for Analog Event Data (OFF,1–3) 2
TIMERQn Time-Set Request Interval (I,M,1–32767 mins) I
DECPLAn Currents Scaling (0–3 decimal places) 1
DECPLVn Voltages Scaling (0–3 decimal places) 1
DECPLMn Misc Data Scaling (0–3 decimal places) 1
STIMEOn Select/Operate Time-Out (0.0–60.0 seconds) 1.0
DNPINAn
c
Seconds to Send Data Link Heartbeat (0–7200) 120
DNPCLn Enable Control Operations (Y, N) N
AIVARn Default Variation for Analog Inputs (1–6) 2
ANADBAn
d
Analog Reporting Dead band for Currents (0–32767) 100
ANADBVn
d
Analog Reporting Dead band for Voltages (0–32767) 100
ANADBMn
d
Analog Reporting Dead band (0–32767) 100
ETIMEOn Event Message Confirm Time-Out (1–50 seconds) 2
UNSOLn
e
Enable Unsolicited Reporting (Y,N) N
PUNSOLn
f
Enable Unsolicited Reporting at Power-Up (Y, N) N
REPADRn DNP Address to Report to (0–65519) 1
NUMEVEn
f
Number of Events to Transmit On (1–200) 10
AGEEVEn
f
Age of Oldest Event to Transmit On (0–99999) 2
Table 12.16 DNP3 Serial Protocol Settings (Sheet 2 of 2)
Label Prompt Default Value
