12.12
SEL-400 Series Relays Instruction Manual Date Code 20171006
Settings
Port Settings
Make Table 12.19 settings if Port setting PROTO := MBA, MBB, MBGA, or MBGB.
URETRYn
f
Unsolicited Message Max Retry Attempts (2–10) 3
UTIMEOn
f
Unsol. Message Offline Time-Out (1–5000 sec) 60
EVEMODn Event Mode (SINGLE, MULTI) SINGLE
a
Hidden if EDNP := 0.
b
Hidden if DNPTRn := TCP.
c
Hidden if DNPTRn := UDP.
d
Hidden if CLASSAn := OFF.
e
Hidden if CLASSAn := CLASSBn := CLASSCn := OFF.
f
Hidden if UNSOLn := N.
Table 12.18 Phasor Measurement Configuration
Setting Prompt Default
EPMIP Enable C37.118 Communications (Y, N)
a
a
Set EPMIP := Y to access remaining settings.
N
PMOTS1 PMU Output 1 Scheme (OFF, TCP, UDP_S, UDP_T, UDP_U) OFF
PMODC1 PMU Output 1 Data Configuration (1–5) 1
PMOIPA1 PMU Output 1 Client IP Address (w.x.y.z)
b
b
Setting hidden when PMOTS1 := OFF.
192.168.1.3
PMOTCP1 PMU Output 1TCP/IP Port Number (1–65534)
b, c, d
c
Setting hidden when PMOTSI := UDP_S.
d
Port # must be unique compared to TPORT and DNPPNUM.
4712
PMOUDP1 PMU Output 1 UDP/IP Data Port Number (1–65534)
b, e
e
Setting hidden when PMOTS1 := TCP.
4713
PMOTS2 PMU Output 2 Scheme (OFF, TCP, UDP_S, UDP_T, UDP_U) OFF
PMODC2 PMU Output 2 Data Configuration (1–5) 1
PMOIPA2 PMU Output 2 Client IP Address (w.x.y.z)
f
f
Setting hidden when PMOTS2 := OFF.
192.168.1.4
PMOTCP2 PMU Output 2 TCP/IP Port Number (1–65534)
d, f, g
g
Setting hidden when PMOTS2 := UDP_S.
4722
PMOUDP2 PMU Output 2 UDP/IP Data Port Number (1–65534)
f, h
h
Setting hidden when PMOTS2 := TCP.
4714
Ta b l e 1 2.1 9 M
IRRORED BITS Protocol Settings (Sheet 1 of 2)
Label Prompt Default Value
TX_ID MIRRORED BITS ID of This Device (1–4) 2
RX_ID M
IRRORED BITS ID of Device Receiving From (1–4) 1
RBADPU Outage Duration to Set RBAD (0–10000 seconds) 10
CBADPU Channel Unavailability to Set CBAD (1–100000 ppm) 20000
TXMODE Transmission Mode (N-Normal, P-Paced) N
MBNUM Number of M
IRRORED BITS Channels (0–8) 8
RMB1FL RMB1 Channel Fail State (0, 1, P) P
RMB1PU RMB1 Pickup Time (1–8 messages) 1
RMB1DO RMB1 Dropout Time (1–8 messages) 1
RMB2FL RMB2 Channel Fail State (0, 1, P) P
Table 12.17 DNP3 LAN/WAN Settings (Sheet 2 of 2)
Label Prompt Default Value
