Report Settings
NOTE: This category is only available
in relays that support 87L
communications.
Report Settings
The SER Points category is a freeform category for listing points to record in the
SER. Each point can be given a reporting name, a set state name, and a clear state
name. You can also indicate whether or not to make this point visible as an alarm
point on the front-panel LCD. The syntax for entry is:
Relay Word Bit Label, "Reporting Name", "Set State Name", "Clear State
Name", HMI Alarm Indication
Each of the names may consist of any printable ASCII character. The HMI alarm
condition is a Y/N choice. By default, there are no SER points configured.
The signal profile settings category consists of a freeform block for selecting ana-
log quantities to include in the signal profile followed by the settings described in
Table 12.40. Any of the analog quantities listed in Section 12:Analog Quantities
in the product-specific instruction manual may be selected. As many as 20 analog
quantities can be included in the signal profile.
Table 12.37 87L Communications Bits
Label
a, b
a
x
= 1–4. These settings are hidden when E87CH = N or 2E or 3E or 4E. Also hidden if there is no
serial communications card installed.
b
nn
= 01–32. These settings are visible when E87CH = 2E, 3E, or 4E, and are hidden in all other cases.
Prompt Default Value
87TxP1 • NA
87TxP2 • NA
87TnnE
•NA
Table 12.38 Report Settings Categories
Settings Reference
SER Chatter Criteria Table 12.39
SER Points
Signal Profile Table 12.40
Event Reporting Table 12.41
HIF Event Reporting
Event Reporting Analog Quantities
Event Reporting Digital Elements
Table 12.39 SER Chatter Criteria
Label Prompt Default Value
ESERDEL Automatic Removal of Chattering SER Points (Y, N) N
SRDLCNT
a
a
Setting is only available if ESERDEL := Y.
Number of Counts Before Auto-Removal (2–20) 5
SRDLTIM
a
Time for Auto-Removal (0.1–30 seconds) 1.0
