14.25
Date Code 20171006 Instruction Manual SEL-400 Series Relays
ASCII Command Reference
Command Description
EVE L
Use EVE L to return a large resolution event report. The Sx option overrides the
L option (see EVE Sx on page 14.26).
EVE L
yyy
Command EVE Lyyy returns a specified length event report, where Lyyy indi-
cates a length of yyy cycles. You can specify yyy from 1 cycle up to a value
including and exceeding the event report total cycle length. If yyy is longer than
the total length, the relay returns the full duration event report. The Lyyy option
overrides the C option.
EVE NEXT
EVE NEXT returns the oldest unacknowledged event report on the present com-
munications port.
EVE NSET
The EVE NSET command returns the event report with no relay settings.
Table 14.60 EVE L Command
Command Description Access Level
EVE L Return the most recent event report at full length with large
resolution data.
1, B, P, A, O, 2
EVE n
a
L
a
Parameter
n
indicates event order or serial number.
Return a particular n event report at full length with large
resolution data.
1, B, P, A, O, 2
Ta b l e 1 4.61 E V E L
yyy
Command
Command
a
a
Parameter
n
indicates event order or serial number; see
EVE on page 14.23
.
Description Access Level
EVE Lyyy Return yyy cycles of the most recent event report (including
settings) with 4-samples/cycle data.
1, B, P, A, O, 2
EVE n Lyyy Return yyy cycles of a particular n event report with 4-sam-
ples/cycle data.
1, B, P, A, O, 2
Table 14.62 EVE N Command
Command Description Access Level
EVE N Return the oldest unacknowledged event report with 4-sam-
ples/cycle data.
1, B, P, A, O, 2
Table 14.63 EVE NSET Command
Command Description Access Level
EVE NSET Return the most recent event report without settings at full
length with 4-samples/cycle data.
1, B, P, A, O, 2
EVE n
a
NSET
a
Parameter
n
indicates event order or serial number; see
EVE on page 14.23
.
Return a particular n event report without settings at full
length with 4-samples/cycle data.
1, B, P, A, O, 2
