14.26
SEL-400 Series Relays Instruction Manual Date Code 20171006
ASCII Command Reference
Command Description
EVE NSUM
The EVE NSUM returns the event report with no event summary.
EVE S
x
Use the EVE Sx command to specify the sample data resolution of the event
report. The sample data resolution x is either 4-samples/cycle or large resolution;
the default value is 4-samples/cycle if you do not specify Sx. The Sx option over-
rides the L option.
EVE Command Option Combinations
You can combine options C, L, Lyyy, n, NSET, NSUM, and Sx, in one com-
mand. Enter the options according to the following guidelines:
➤ The Lyyy option overrides the C option.
➤ The Sx option overrides the L option.
➤ When choosing option A or option D as a report type, you cannot use
option C to specify the report length at 15 cycles. Use option Lyyy at
L015 to specify a 15-cycle report.
➤ Enter the options in any order.
Table 14.66 lists the choices you can make in the EVE command. Combine
options on each row, selecting one option from each column, to create an EVE
command.
Ta b l e 1 4.64 EVE N S U M Com m a n d
Command Description Access Level
EVE NSUM Return the most recent event report without the event sum-
mary at full length with 4-samples/cycle data.
1, B, P, A, O, 2
EVE n
a
NSUM
a
Parameter
n
indicates event order or serial number.
Return a particular n event report without the event sum-
mary at full length with 4-samples/cycle data.
1, B, P, A, O, 2
Table 14.65 EVE S
x
Command
Command Description Access Level
EVE Sx Return the most recent event report at full length with x-sam-
ples/cycle data.
1, B, P, A, O, 2
EVE n
a
Sx
a
Parameter
n
indicates event order or serial number;
x
is 4, 8, or 12 to represent data at
4 samples/cycle, 8 samples/cycle, or 12 samples/cycle respectively. See the product-specific
instruction manual to see whether 8 or 12 samples/cycle are supported for larger resolution reports.
Return a particular n event report at full length with x-sam-
ples/cycle data.
1, B, P, A, O, 2
Table 14.66 EVE Command Option Groups
Acknowledge
Event
Number
Data
Resolution
Report
Type
Report
Length
Omit
ACK n, NEXT Sx, L C, A, D Lyyy, C NSET, NSUM
