14.27
Date Code 20171006 Instruction Manual SEL-400 Series Relays
ASCII Command Reference
Command Description
The following examples illustrate some possible option combinations.
EXIT
Use the EXIT command to terminate a Telnet session and revert to Access Level 0
(exit relay control).
FILE
The FILE command provides a safe and efficient means of transferring files
between IEDs and external support software (ESS) by providing Ymodem file
transfer. The FILE commands are especially useful for retrieving high-resolution
sampled data in binary COMTRADE format from the relay.
All text enclosed in [brackets] indicates optional command line parameters. The
specific directories available in the relay depends on the relay model, but typi-
cally includes EVENTS, REPORTS, SETTINGS, and SYNCHROPHASOR
directories. For FILE READ operations, specify the directory parameters as
needed. The FILE WRITE command is available only for the SETTINGS directory.
Table 14.67 EVE Command Examples
Example Description
EVE L010 S8 Return 10 cycles of an 8-samples/cycle event report for the most recent event.
EVE L10 A Return 10 cycles of the analog portion only of the most recent event report
at 4-samples/cycle resolution.
EVE 2 C NSUM For the second most recent event, return the event with 8-samples/cycle
data, and omit the event summary.
Ta b l e 1 4.68 E X I T Comm a n d
Command Description Access Level
EXIT Terminate the Ethernet port Telnet sessions and go to
Access Level 0 (exit relay control)
0, 1, B, P, A, O, 2
Ta b l e 1 4.69 F I L E C o m m a n d
Command Description Access Level
FILE DIR
directory
Returns a list of filenames in specified directory (direc-
tory). If not specified, then the list of files and directories in
the root directory is returned.
1, B, P, A, O, 2
FILE READ
directory
filename
Initiates a file transfer of the file filename (in the folder
directory) from the relay to external support software. The
filename parameter is required.
1, B, P, A, O, 2
FILE
WRITE
SETTINGS
filename
Initiates a file transfer of the file filename from external
support software to the relay. If the filename parameter is
not specified, the file name must be given in the Ymodem
header.
P, A, O, 2
