14.30
SEL-400 Series Relays Instruction Manual Date Code 20171006
ASCII Command Reference
Command Description
When reporting a list of subscriptions with the GOO S command, the response
includes the subscription ID, the application identifier, and the GOOSE control
block reference. The other variants of GOO S provide statistics on the selected
subscriptions. Figure 14.4 and Figure 14.5 illustrates this.
GOO S ALL L Display GOOSE statistics for all subscriptions including
error history.
1,B,P,A,O,2
GOO S n C Clear GOOSE statistics for subscription ID n. 1,B,P,A,O,2
GOO S ALL C Clear GOOSE statistics for all subscriptions. 1,B,P,A,O,2
==>goo s 2 <Enter>
SubsID 2
-----------------------------------------------------------------------------
Ctrl Ref: GOOSE_SIM_CFG/LLN0$GO$GooseDSet02
AppID : 4114
From : 06/30/2014 10:59:29.760 To: 06/30/2014 11:10:32.817
Accumulated downtime duration : 0000:10:59.325
Maximum downtime duration : 0000:10:59.325
Date & time maximum downtime began : 06/30/2014 10:59:33.492
Number of messages received out-of-sequence(OOS) : 0
Number of time-to-live(TTL) violations detected : 1
Number of messages incorrectly encoded or corrupted: 654
Number of messages lost due to receive overflow : 0
Calculated max. sequential messages lost due to OOS: 0
Calculated number of messages lost due to OOS : 0
Figure 14.4 Example GOO S Command Response
=>>GOO S ALL L <Enter>
SubsID 1
-----------------------------------------------------------------------------
Ctrl Ref: GOOSE_SIM_CFG/LLN0$GO$GooseDSet01
AppID : 4113
From : 07/01/2014 11:23:13.851 To: 07/01/2014 11:37:54.790
Figure 14.5 Example GOO S ALL L Command Response (Sheet 1 of 2)
Table 14.72 GOO S Command (Sheet 2 of 2)
Command Description Access Level
