Schweitzer Engineering Laboratories SEL-421-4 - Page 1235

14.29
Date Code 20171006 Instruction Manual SEL-400 Series Relays
ASCII Command Reference
Command Description
An example response to the GOOSE commands is shown in Figure 14.3.
If the GOOSE command is issued during CID file processing, the relay responds
with
CID file is currently being processed. No GOOSE statistics
available
. When GOOSE is disabled by settings (EGSE = N), the relay sends
Command is not available in responding to a GOOSE command. If an error is
detected during the processing of the IEC 61850 file, the relay responds with
Error detected in parsing the CID file. All GOOSE processing dis-
abled
to a GOOSE command.
GOO S
The GOO S command provides statistics for GOOSE subscriptions.
Transmit Data Set
Reference
This field represents the datSetRef (Data Set Reference) that includes
the IED name, LN0 lnClass (Logical Node Class), and GSEControl
datSet (Data Set Name) (e.g., SEL_411L_1CFG/LLN0$DSet13).
Receive Data Set
Reference
This field represents the datSetRef (Data Set Reference) that includes
the iedName (IED name), ldInst (Logical Device Instance), LN0
lnClass (Logical Node Class) and datSet (Data Set Name) (e.g.,
SEL_411L_1CFG/LLN0$DSet13).
=>>GOOSE <Enter>
GOOSE Transmit Status
MultiCastAddr Ptag:Vlan StNum SqNum TTL Code
-----------------------------------------------------------------------------
SEL_411L_OtterCFG/LLN0$GO$GooseDSet13
01-0C-CD-01-00-10 4:1 1 166 457
Data Set: SEL_411L_OtterCFG/LLN0$DSet13
GOOSE Receive Status
MultiCastAddr Ptag:Vlan StNum SqNum TTL Code
-----------------------------------------------------------------------------
SEL_411L_1CFG/LLN0$GO$GooseDSet13
01-0C-CD-01-00-04 : 0 0 0 TTL EXPIRED
Data Set: SEL_487B_1CFG/LLN0$DSet13
SEL_2440_1CFG/LLN0$GO$GooseDSet13
01-0C-CD-01-00-0A : 0 0 0 TTL EXPIRED
Data Set: SEL_2440_1CFG/LLN0$DSet13
SEL_487E_1CFG/LLN0$GO$GooseDSet13
01-0C-CD-01-00-10 : 0 0 0 TTL EXPIRED
Data Set: SEL_487E_1CFG/LLN0$DSet13
SEL_710_1CFG/LLN0$GO$GooseDSet13
01-0C-CD-01-00-08 : 0 0 0 TTL EXPIRED
Data Set: SEL_710_1CFG/LLN0$DSet13
Figure 14.3 GOOSE Command Response
Table 14.71 Accessible GOOSE IED Information (Sheet 2 of 2)
IED Description
Table 14.72 GOO S Command (Sheet 1 of 2)
Command Description Access Level
GOO S Display a list of GOOSE subscriptions with their ID. 1,B,P,A,O,2
GOO S n Display GOOSE statistics for subscription ID n. 1,B,P,A,O,2
GOO S ALL Display GOOSE statistics for all subscriptions. 1,B,P,A,O,2
GOO S n L Display GOOSE statistics for subscription ID n includ-
ing error history.
1,B,P,A,O,2
