16.32
SEL-400 Series Relays Instruction Manual Date Code 20171006
DNP3 Communication
DNP3 LAN/WAN Application Example
Settings
Use QuickSet to enter the DNP3 protocol settings and new data map into the relay.
RB05 10, 12 4 Remote Bit 5
RB06 10, 12 5 Remote Bit 6
OCS:CCS 10, 12 6 Circuit Breaker S trip/close pair
IASFMC 30, 32 0 A-Phase Current magnitude
IASFAC 30, 32 1 A-Phase Current angle
IBSFMC
a
30, 32 2 B-Phase Current magnitude
IBSFAC
b
30, 32 3 B-Phase Current angle
ICSFMC
a
30, 32 4 C-Phase Current magnitude
ICSFAC
b
30, 32 5 C-Phase Current angle
VAVFMC 30, 32 6 VA Phase Voltage magnitude, Terminal V
VAV FA C
b
30, 32 7 VA Phase Voltage angle, Terminal V
VBVFMC
c
30, 32 8 VB Phase Voltage magnitude, Terminal V
VBVFAC
b
30, 32 9 VB Phase Voltage angle, Terminal V
VCVFMC
c
30, 32 10 VC Phase Voltage magnitude, Terminal V
VCVFAC
b
30, 32 11 VC Phase Voltage angle, Terminal V
VDC
d
30, 32 12 VDC voltage multiplied by 100
ACTGRP 40 0 Active settings group
a
Assume the largest expected current is 2000 A, scale the analog value by a factor of 10 to
provide a resolution of 0.1 A and a maximum current of 3276.7 A. Report change events on a
change of 5 A.
b
Angles are scaled to 1/100 of a degree. Report change events on a change of 2 degrees.
c
For a nominal voltage of 230 kV, scale the analog value by a factor of 100 to provide a resolution
of 10 V and a maximum value of 327.67 kV. Report 1 kV for change event reporting.
d
VDC1 is scaled by a factor of 1/100 of a volt. Report change events on a change of 2 V.
Table 16.13 DNP3 Application Example Data Map (Sheet 2 of 2)
Label Object
Custom Map
Index
Description
Table 16.14 DNP3 LAN/WAN Application Example Protocol Settings (Sheet 1 of 2)
Setting Name Setting Description
EPORT Y Enable Ethernet port
IPADDR 192.9.0.2/16 Relay IP address and network in CIDR notation
DEFRTR 192.9.0.1 Default router
EDNP 1 Enable DNP3 LAN/WAN Session 1
DNPADR 101 DNP3 address for relay is 101
DNPPNUM 20000
a
DNP3 port number for TCP
DNPID RELAY1DNP DNP3 ID for Object 0 self-description
DNPIP1 192.9.0.3 DNP3 Master (RTU) IP address
DNPTR1 TCP Use TCP transport
DNPMAP1 1 Use DNP3 Map 1 for DNP3 LAN/WAN Session 1
CLASSB1 1 Binary event data = Class 1
CLASSC1 1 Counter event data = Class 1
