Date Code 20171006 Instruction Manual SEL-400 Series Relays
IEC 61850 Communication
Logical Nodes
Table 17.11 shows the LNs associated with control elements, defined as Logical
Device CON.
Table 17.11 Logical Device: CON (Remote Control) (Sheet 1 of 2)
Logical Node Attribute
Data
Source
Comment
Functional Constraint = CO
RBGGIO1 SPCSO01.Oper.ctlVal RB01 Remote Bit 1
RBGGIO1 SPCSO02.Oper.ctlVal RB02 Remote Bit 2
RBGGIO1 SPCSO03.Oper.ctlVal RB03 Remote Bit 3
RBGGIO1 SPCSO04.Oper.ctlVal RB04 Remote Bit 4
RBGGIO1 SPCSO05.Oper.ctlVal RB05 Remote Bit 5
RBGGIO1 SPCSO06.Oper.ctlVal RB06 Remote Bit 6
RBGGIO1 SPCSO07.Oper.ctlVal RB07 Remote Bit 7
RBGGIO1 SPCSO08.Oper.ctlVal RB08 Remote Bit 8
RBGGIO2 SPCSO09.Oper.ctlVal RB09 Remote Bit 9
RBGGIO2 SPCSO10.Oper.ctlVal RB10 Remote Bit 10
RBGGIO2 SPCSO11.Oper.ctlVal RB11 Remote Bit 11
RBGGIO2 SPCSO12.Oper.ctlVal RB12 Remote Bit 12
RBGGIO2 SPCSO13.Oper.ctlVal RB13 Remote Bit 13
RBGGIO2 SPCSO14.Oper.ctlVal RB14 Remote Bit 14
RBGGIO2 SPCSO15.Oper.ctlVal RB15 Remote Bit 15
RBGGIO2 SPCSO16.Oper.ctlVal RB16 Remote Bit 16
RBGGIO3 SPCSO17.Oper.ctlVal RB17 Remote Bit 17
RBGGIO3 SPCSO18.Oper.ctlVal RB18 Remote Bit 18
RBGGIO3 SPCSO19.Oper.ctlVal RB19 Remote Bit 19
RBGGIO3 SPCSO20.Oper.ctlVal RB20 Remote Bit 20
RBGGIO3 SPCSO21.Oper.ctlVal RB21 Remote Bit 21
RBGGIO3 SPCSO22.Oper.ctlVal RB22 Remote Bit 22
RBGGIO3 SPCSO23.Oper.ctlVal RB23 Remote Bit 23
RBGGIO3 SPCSO24.Oper.ctlVal RB24 Remote Bit 24
RBGGIO4 SPCSO25.Oper.ctlVal RB25 Remote Bit 25
RBGGIO4 SPCSO26.Oper.ctlVal RB26 Remote Bit 26
RBGGIO4 SPCSO27.Oper.ctlVal RB27 Remote Bit 27
RBGGIO4 SPCSO28.Oper.ctlVal RB28 Remote Bit 28
RBGGIO4 SPCSO29.Oper.ctlVal RB29 Remote Bit 29
RBGGIO4 SPCSO30.Oper.ctlVal RB30 Remote Bit 30
RBGGIO4 SPCSO31.Oper.ctlVal RB31 Remote Bit 31
RBGGIO4 SPCSO32.Oper.ctlVal RB32 Remote Bit 32
Functional Constraint = DC
CTRLLPHD1 PhyNam.model PARNUM Relay part number string
Functional Constraint = ST
RBGGIO1
a
SPCSO01.stVal RB01 Remote Bit 1
RBGGIO1
a
SPCSO02.stVal RB02 Remote Bit 2
