Schweitzer Engineering Laboratories SEL-421-4 - Page 1382

17.32
SEL-400 Series Relays Instruction Manual Date Code 20171006
IEC 61850 Communication
Logical Nodes
RBGGIO1
a
SPCSO03.stVal RB03 Remote Bit 3
RBGGIO1
a
SPCSO04.stVal RB04 Remote Bit 4
RBGGIO1
a
SPCSO05.stVal RB05 Remote Bit 5
RBGGIO1
a
SPCSO06.stVal RB06 Remote Bit 6
RBGGIO1
a
SPCSO07.stVal RB07 Remote Bit 7
RBGGIO1
a
SPCSO08.stVal RB08 Remote Bit 8
RBGGIO2
a
SPCSO09.stVal RB09 Remote Bit 9
RBGGIO2
a
SPCSO10.stVal RB10 Remote Bit 10
RBGGIO2
a
SPCSO11.stVal RB11 Remote Bit 11
RBGGIO2
a
SPCSO12.stVal RB12 Remote Bit 12
RBGGIO2
a
SPCSO13.stVal RB13 Remote Bit 13
RBGGIO2
a
SPCSO14.stVal RB14 Remote Bit 14
RBGGIO2
a
SPCSO15.stVal RB15 Remote Bit 15
RBGGIO2
a
SPCSO16.stVal RB16 Remote Bit 16
RBGGIO3
a
SPCSO17.stVal RB17 Remote Bit 17
RBGGIO3
a
SPCSO18.stVal RB18 Remote Bit 18
RBGGIO3
a
SPCSO19.stVal RB19 Remote Bit 19
RBGGIO3
a
SPCSO20.stVal RB20 Remote Bit 20
RBGGIO3
a
SPCSO21.stVal RB21 Remote Bit 21
RBGGIO3
a
SPCSO22.stVal RB22 Remote Bit 22
RBGGIO3
a
SPCSO23.stVal RB23 Remote Bit 23
RBGGIO3
a
SPCSO24.stVal RB24 Remote Bit 24
RBGGIO4
a
SPCSO25.stVal RB25 Remote Bit 25
RBGGIO4
a
SPCSO26.stVal RB26 Remote Bit 26
RBGGIO4
a
SPCSO27.stVal RB27 Remote Bit 27
RBGGIO4
a
SPCSO28.stVal RB28 Remote Bit 28
RBGGIO4
a
SPCSO29.stVal RB29 Remote Bit 29
RBGGIO4
a
SPCSO30.stVal RB30 Remote Bit 30
RBGGIO4
a
SPCSO31.stVal RB31 Remote Bit 31
RBGGIO4
a
SPCSO32.stVal RB32 Remote Bit 32
a
Data source is high-speed GOOSE data if included in an outgoing GOOSE dataset.
Table 17.11 Logical Device: CON (Remote Control) (Sheet 2 of 2)
Logical Node Attribute
Data
Source
Comment
