17.33
Date Code 20171006 Instruction Manual SEL-400 Series Relays
IEC 61850 Communication
Logical Nodes
Table 17.12 shows the LNs associated with the annunciation element, defined as
Logical Device ANN.
Table 17.12 Logical Device: ANN (Annunciation) (Sheet 1 of 11)
Logical Node Attribute
Data
Source
Comment
Functional Constraint = DC
STALPHD1 PhyNam.model PARNUM Relay part number string
Functional Constraint = MX
ACNGGIO2 AnIn001.instMag.f ACN01CV Automation SELOGIC Counter 01 current
value
ACNGGIO2 AnIn002.instMag.f ACN02CV Automation SEL
OGIC Counter 02 current
value
ACNGGIO2 AnIn003.instMag.f ACN03CV Automation SEL
OGIC Counter 03 current
value
•
•
•
ACNGGIO2 AnIn014.instMag.f ACN14CV Automation SEL
OGIC Counter 14 current
value
ACNGGIO2 AnIn015.instMag.f ACN15CV Automation SEL
OGIC Counter 15 current
value
ACNGGIO2 AnIn016.instMag.f ACN16CV Automation SEL
OGIC Counter 16 current
value
AMVGGIO1 AnIn001.instMag.f AMV001 Automation SEL
OGIC Math Variable 001
AMVGGIO1 AnIn002.instMag.f AMV002 Automation SEL
OGIC Math Variable 002
AMVGGIO1 AnIn003.instMag.f AMV003 Automation SEL
OGIC Math Variable 003
•
•
•
AMVGGIO1 AnIn062.instMag.f AMV062 Automation SEL
OGIC Math Variable 062
AMVGGIO1 AnIn063.instMag.f AMV063 Automation SEL
OGIC Math Variable 063
AMVGGIO1 AnIn064.instMag.f AMV064 Automation SEL
OGIC Math Variable 064
AMVGGIO2 AnIn065.instMag.f AMV065 Automation SEL
OGIC Math Variable 065
AMVGGIO2 AnIn066.instMag.f AMV066 Automation SEL
OGIC Math Variable 066
AMVGGIO2 AnIn067.instMag.f AMV067 Automation SEL
OGIC Math Variable 067
•
•
•
AMVGGIO2 AnIn126.instMag.f AMV126 Automation SEL
OGIC Math Variable 126
AMVGGIO2 AnIn127.instMag.f AMV127 Automation SEL
OGIC Math Variable 127
AMVGGIO2 AnIn128.instMag.f AMV128 Automation SEL
OGIC Math Variable 128
PCNGGIO1 AnIn001.instMag.f PCN01CV Protection SEL
OGIC Counter 01 current
value
PCNGGIO1 AnIn002.instMag.f PCN02CV Protection SEL
OGIC Counter 02 current
value
PCNGGIO1 AnIn003.instMag.f PCN03CV Protection SEL
OGIC Counter 03 current
value
NOTE: Some products support only
64 AMVs in their ANN Logical Device.
