2.4
SEL-400 Series Relays Instruction Manual Date Code 20171006
PC Software
Settings Database Management and Drivers
Step 6. Use the Save to Address Book button to save the entered informa-
tion with a Connection Name for later use.
Step 7. Set the relay Ethernet port setting FTPSERV to Y.
Telnet Setup
Step 1. Access the Network dialog box from the Active Connection Type
drop-down menu.
Step 2. Click the Telnet File Transfer Option button to select Telnet as the
network communications protocol.
The Telnet session uses the relay passwords on the Communication Parameters
dialog box (Figure 2.1). See Telnet on page 15.13 for more information on Tel-
net.
Terminal Window
The terminal window provides an ASCII interface on which you can communi-
cate with the relay. This is a basic terminal emulation. Many third-party terminal
emulation programs are available with file transfer encoding schemes.
Step 1. Click the QuickSet Communication menu.
Step 2. Click Terminal to start the terminal window.
Another convenient method to start the terminal is to press <Ctrl+T>.
Terminal Logging
When you select the Terminal Logging check box in the Communication
menu, QuickSet records communications events and errors in a log.
Step 1. Click Communication > Logging > Connection Log to view the log.
Step 2. Clear the log by selecting Communication > Logging > Clear Con-
nection Log.
Settings Database Management and Drivers
Database Manager
QuickSet uses a relay database to save relay settings. QuickSet contains sets of
all settings files for each relay that you specify in the Database Manager.
Choose appropriate storage backup methods and a secure location for storing
your relay database files. Use the File > Database Manager menu to retrieve a
relay database from computer memory.
