2.20
SEL-400 Series Relays Instruction Manual Date Code 20171006
PC Software
QuickSet HMI
Phasors A graphical and textual representation of phase and sequence
voltages and currents.
Time and
Communications
View for Time Quality, M
IRRORED BITS Channel A or B,
RTC Channel. PTP, or Sampled Values status.
Fundamental Metering A table of instantaneous voltages, currents, powers, and fre-
quency.
Zone Metering View active Zone meter reports.
Differential Metering View differential currents of all active zones.
Unbalance Metering View the differential and unbalanced metering data.
Synchrophasor A table of synchrophasor data.
Demand/Peak A table showing demand and peak demand values. This display
also allows demand and peak demand values to be reset.
Min/Max A table showing maximum/minimum metering quantities. This
display also allows maximum/minimum metering quantities to be
reset.
Energy A table showing energy import/export. This display also allows
energy values to be reset.
Temperature View the temperature measurements received from the
SEL-2600A.
Protection Math Variables View the protection math variable values.
Automation Math Vari-
ables
View the automation math variable values.
M
IRRORED BITS Commu-
nications
View the MIRRORED BITS communications analog quantities.
Through Faults View the through-fault data.
Thermal Monitoring View the most recent saved thermal report of the transformer(s)
monitored by the device.
Breaker n Monitoring
(n can be S,T,U,W, or X)
View a comprehensive circuit breaker report that includes inter-
rupted currents, number of operations, and mechanical and elec-
trical operating times.
Analog Signal Profile View the Signal Profile data for as many as 20 user-selectable
analog values.
VSSI Report View the voltage sag, swell, and interruption report.
Targets View Relay Word bits in a row/column format.
Status A list of relay status conditions.
LDP View load profile data.
SER Sequential Events Recorder (SER) data listed oldest to newest,
top to bottom.
Set the range of SER records with the dialog boxes at the bottom
of the display.
SSI View voltage Sag, Swell, and Interruption data.
Breaker Monitor Data A table showing the latest circuit breaker monitor data.
Control Window Metering and records reset buttons, trip and close control, output
pulsing, target reset, time and date set, group switch, and remote
bit control.
Table 2.2 QuickSet HMI Tree View Functions (Sheet 2 of 2)
Function Description
