Procedure
1. Press the "Machine" operating area key
2. Press the <JOG> key.
3. Press the "Stock removal" softkey.
4. Enter desired values for the parameters.
5. Press the "OK" softkey.
The parameter screen is closed.
6. Press the <CYCLE START> key.
The "Stock removal" cycle is started.
You can return to the parameter screen form at any time to check and
correct the inputs.
Parameters Description Unit
T Tool name
D Cutting edge number
F Feedrate mm/rev
S / V Spindle speed or constant cutting rate rpm
m/min
Spindle M function Direction of spindle rotation (only when ShopTurn is not active)
●
●
Machining
● ∇ (roughing)
● ∇∇∇ (finishing)
Position Machining position
Machining
direction
● Face
● Longitudinal
X0 Reference point ∅ (abs) mm
Working in manual mode
5.6 Simple stock removal of workpiece
Turning
148 Operating Manual, 06/2019, A5E44903486B AB
