Tool change point Machine
XT 160 abs
ZT 409 abs
SC 1
S1 4000 rev/min
Machining direction Climbing
2. Press the "Accept" softkey.
The work plan is displayed. Program header and end of program are
created as program blocks.
The end of program is automatically defined.
2. Stock removal cycle for facing
1. Press the "Turning" and "Stock removal" softkeys.
2. Select the machining strategy.
3. Enter the following technology parameters:
T Roughing
tool_80
D1 F 0.300 mm/rev V 350 m/min
4. Enter the following parameters:
Machining Roughing (∇)
Position
Direction Face (parallel to the X axis)
X0 90 abs
Z0 2 abs
X1 -1.6 abs
Z1 0 abs
D 2 inc
UX 0 inc
UZ 0.1 inc
5. Press the "Accept" softkey.
Creating a ShopTurn program
9.19 Example: Standard machining
Turning
328 Operating Manual, 06/2019, A5E44903486B AB
