4. Press the "Accept" softkey.
Contour, groove
9. Groove (finishing)
1. Press the "Turning", "Groove" and "Groove with inclines" softkeys.
The "Groove 2" entry field opens.
2. Enter the following technology parameters:
T Grooving tool D1 F 0.1 mm/rev V 220 m/min
3. Enter the following parameters:
Machining Finishing (∇∇∇)
Groove position
Reference point
X0 60 abs
Z0 -70
B1 5.856 inc
T1 4 inc
α1 15 degrees
α2 15 degrees
FS1 1
Creating a ShopTurn program
9.19 Example: Standard machining
Turning
Operating Manual, 06/2019, A5E44903486B AB 335
