Parameter Description Unit
X0
Y0
α0
(only for G Code)
X coordinate of the reference point X (abs)
This position must be programmed absolutely in the 1st call.
Y coordinate of the reference point Y (abs)
This position must be programmed absolutely in the 1st call.
Angle of rotation of the line referred to the X axis
Positive angle: Line is rotated counter-clockwise.
Negative angle: Line is rotated clockwise.
mm
mm
Degrees
Z0
X0
Y0
α0
(only for Shop‐
Turn)
Face C:
Z coordinate of the reference point (abs)
X coordinate of the reference point – first position (abs)
Y coordinate of the reference point – first position (abs)
Angle of rotation of line in relation to the X axis
Positive angle: Line is rotated counter-clockwise.
Negative angle: Line is rotated clockwise.
mm
mm
mm
Degrees
Z0
CP
X0
Y0
α0
(only for Shop‐
Turn)
Face Y:
Z coordinate of the reference point (abs)
Positioning angle for machining area
The CP angle does not have any effect on the machining position in relation to the work‐
piece. It is only used to position the workpiece with the rotary axis C in such a way that
machining is possible on the machine.
X coordinate of the reference point – first position (abs)
Y coordinate of the reference point – first position (abs)
Angle of rotation of line in relation to the X axis
Positive angle: Line is rotated counter-clockwise.
Negative angle: Line is rotated clockwise.
mm
Degrees
mm
mm
Degrees
X0
Y0
Z0
α0
(only for Shop‐
Turn)
Peripheral surface C:
Cylinder diameter ∅ (abs)
Y coordinate of the reference point – first position (abs)
Z coordinate of the reference point – first position (abs)
Angle of rotation of line with reference to Y axis
Positive angle: Line is rotated counter-clockwise.
Negative angle: Line is rotated clockwise.
mm
mm
mm
Degrees
Programming technology functions (cycles)
10.1 Drilling
Turning
394 Operating Manual, 06/2019, A5E44903486B AB
