Parameter Description Unit
X0
C0
Y0
Z0
α0
(only for Shop‐
Turn)
Peripheral surface Y:
X coordinate of the reference point (abs)
Positioning angle for machining surface
Y coordinate of the reference point – first position (abs)
Z coordinate of the reference point – first position (abs)
Angle of rotation of line with reference to Y axis
Positive angle: Line is rotated counter-clockwise.
Negative angle: Line is rotated clockwise.
mm
Degrees
mm
mm
Degrees
αX
αY
L1
L2
N1
N2
Shear angle X
Shear angle Y
Distance between columns
Distance between rows
Number of columns
Number of rows
Degrees
Degrees
mm
mm
Parameters - "Frame" position pattern
Parameter Description Unit
LAB
(only for G code)
Repeat jump label for position
PL
(only for G code)
Machining plane
Machining
surface
(only for Shop‐
Turn)
● Face C
● Face Y
● Peripheral surface C
● Peripheral surface Y
Position
(only for Shop‐
Turn)
● At the front (face)
● At the rear (face)
● Outside (peripheral surface)
● Inside (peripheral surface)
X0
Y0
α0
(only for G Code)
X coordinate of the reference point X (abs)
This position must be programmed absolutely in the 1st call.
Y coordinate of the reference point Y (abs)
This position must be programmed absolutely in the 1st call.
Angle of rotation of the line referred to the X axis
Positive angle: Line is rotated counter-clockwise.
Negative angle: Line is rotated clockwise.
mm
mm
Degrees
Programming technology functions (cycles)
10.1 Drilling
Turning
Operating Manual, 06/2019, A5E44903486B AB 395
