Parameters Description Unit
Undercut Form E Undercut size
e.g. E1.0x0.4
Form F Undercut size
e.g. F0.6x0.3
DIN thread P
α
Thread pitch
Insertion angle
mm/rev
Degrees
Thread Z1
Z2
R1
R2
T
Length Z1
Length Z2
Radius R1
Radius R2
Insertion depth
mm
mm
mm
mm
mm
Chamfer FS Transition to following element - chamfer mm
CA Grinding allowance
● Grinding allowance to right of contour
● Grinding allowance to left of contour
mm
Additional commands Additional G code commands
Contour element "Straight line e.g. X"
Parameters Description Unit
X End point X ∅ (abs) or end point X (inc) mm
α1 Starting angle to Z axis Degrees
α2 Angle to the preceding element Degrees
Transition to next ele‐
ment
Type of transition
● Radius
● Undercut
● Chamfer
Radius R Transition to following element - radius mm
Undercut Form E Undercut size
e.g. E1.0x0.4
Form F Undercut size
e.g. F0.6x0.3
DIN thread P
α
Thread pitch
Insertion angle
mm/rev
Degrees
Thread Z1
Z2
R1
R2
T
Length Z1
Length Z2
Radius R1
Radius R2
Insertion depth
mm
mm
mm
mm
mm
Chamfer FS Transition to following element - chamfer mm
CA Grinding allowance
● Grinding allowance to right of contour
● Grinding allowance to left of contour
mm
Additional commands Additional G code commands
Programming technology functions (cycles)
10.3 Contour turning
Turning
450 Operating Manual, 06/2019, A5E44903486B AB
