G code program parameters ShopTurn program parameters
Input
● Complete
PRG
● Name of the program to be generated
● Auto
Automatic generation of program names
T Tool name
PL Machining plane D Cutting edge number
RP Retraction plane – (only for
machining direction, longitu‐
dinal, inner)
mm F Feedrate mm/rev
SC Safety clearance mm S / V Spindle speed or constant cutting
rate
rpm
m/min
F Feedrate *
Residual
material
With subsequent residual material removal
● Yes
● No
CONR Name to save the updated unmachined-part
contour for residual material removal - (only
"Yes" for residual material removal)
Parameter Description Unit
Machining
● ∇ (roughing)
● ∇∇∇ (finishing)
● ∇+∇∇∇ (complete machining)
Machining
direction
● Face
● Longitudinal
Position
● front
● rear
● Internal
● external
D Maximum depth infeed - (only for ∇) mm
XDA First grooving limit tool (abs) – (only for face machining direction) mm
XDB Second grooving limit tool (abs) – (only for face machining direction) mm
UX or U Finishing allowance in X or finishing allowance in X and Z – (only for ∇) mm
UZ Finishing allowance in Z – (only for UX) mm
DI For zero: Continuous cut - (only for ∇) mm
BL Blank description (only for ∇)
● Cylinder (described using XD, ZD)
● Allowance (XD and ZD on the finished part contour)
● Contour (additional CYCLE62 call with blank contour – e.g. cast iron mold)
Programming technology functions (cycles)
10.3 Contour turning
Turning
470 Operating Manual, 06/2019, A5E44903486B AB
