Parameter Description Unit
XD - (only for ∇ machining)
- (only for blank description, cylinder and allowance)
● For blank description, cylinder
– Version, absolute:
Cylinder dimension ∅ (abs)
– Version incremental:
Allowance (inc) to maximum values of the CYCLE62 finished part contour
● For blank description, allowance
– Allowance on the CYCLE62 finished part contour (inc)
mm
ZD - (only for ∇ machining)
- (only for blank description, cylinder and allowance)
● For blank description, cylinder
– Version, absolute:
Cylinder dimension (abs)
– Version incremental:
Allowance (inc) to maximum values of the CYCLE62 finished part contour
● For blank description, allowance
Allowance on the CYCLE62 finished part contour (inc)
mm
Allowance Allowance for pre-finishing - (only for ∇∇∇)
● Yes
U1 contour allowance
● No
mm
U1 Compensation allowance in X and Z direction (inc) – (only for allowance)
● Positive value: Compensation allowance is retained
● Negative value: Compensation allowance is removed in addition to finishing
allowance
mm
Set machining area
limits
Set machining area limits
● Yes
● No
XA
XB
ZA
ZB
with limited machining area only, yes:
1. Limit XA ∅
2. Limit XB ∅ (abs) or 2nd limit referred to XA (inc)
1. Limit ZA
2. Limit ZB (abs) or 2nd limit referred to ZA (inc)
mm
N Number of grooves
DP Distance between grooves (inc) mm
* Unit of feedrate as programmed before the cycle call
Programming technology functions (cycles)
10.3 Contour turning
Turning
Operating Manual, 06/2019, A5E44903486B AB 471
