G code program parameters ShopTurn program parameters
PL Machining plane T Tool name
RP Retraction plane mm F Feedrate mm/min
mm/tooth
SC Safety clearance mm S / V Spindle speed or constant cutting
rate
rpm
m/min
F Feedrate *
Parameter Description Unit
Machining surface
(only for Shop‐
Turn)
● Face Y
● Peripheral surface Y
(only for Shop‐
Turn)
Clamp/release spindle
The function must be set up by the machine manufacturer.
Machining The following machining technologies can be selected:
● ∇ (roughing)
● ∇∇∇ (finishing)
Direction Same direction of machining
●
●
Alternating direction of machining
●
●
(only for G code)
X0
Y0
Z0
X1
Y1
Z1
The positions refer to the reference point:
Corner point 1 in X
Corner point 1 in Y
Height of blank
Corner point 2X (abs) or corner point 2X in relation to X0 (inc)
Corner point 2Y (abs) or corner point 2Y in relation to Y0 (inc)
Height of blank (abs) or height of blank in relation to Z0 (inc)
mm
mm
mm
mm
mm
mm
Programming technology functions (cycles)
10.4 Milling
Turning
Operating Manual, 06/2019, A5E44903486B AB 487
