Parameters in the "Input simple" mode
G code program parameters ShopTurn program parameters
Input
● simple
Milling direction T Tool name
RP Retraction plane mm D Cutting edge number
F Feedrate * F Feedrate mm/min
mm/rev
S / V Spindle speed or constant
cutting rate
rpm
m/min
Parameter Description
Machining
surface (only for
ShopTurn)
● Face C
● Face Y
● Peripheral surface C
● Peripheral surface Y
Position (only for
ShopTurn)
● At the front (face)
● At the rear (face)
● Outside (peripheral surface)
● Inside (peripheral surface)
(only for ShopTurn)
Clamp/release spindle (only for end face Y/peripheral surface Y)
The function must be set up by the machine manufacturer.
Machining
● ∇ (roughing)
● ∇∇∇ (finishing)
● ∇∇∇ edge (edge finishing, plane-by-plane or helical)
● Chamfering
Machining type
● Plane by plane
Solid machine circular pocket plane-by-plane
● Helical
Solid machine circular pocket helically
X0
Y0
Z0
(only for G code)
The positions refer to the reference point:
Reference point X
Reference point Y
Reference point Z
mm
mm
mm
Programming technology functions (cycles)
10.4 Milling
Turning
504 Operating Manual, 06/2019, A5E44903486B AB
