Parameter Description
X0 or L0
Y0 or C0
Z0 (only for Shop‐
Turn)
Face C: The positions refer to the reference point:
Reference point X or reference point length polar
Reference point Y or reference point angle polar
Reference point Z
mm
mm or
degrees
mm
CP
X0 or L0
Y0 or C0
Z0 (only for Shop‐
Turn)
Face Y: The positions refer to the reference point:
Positioning angle for machining area
Angle CP does not have any effect on the machining position in relation to the workpiece.
It is only used to position the workpiece with the rotary axis C in such a way that ma‐
chining is possible on the machine.
Reference point X or reference point length polar
Reference point Y or reference point angle polar
Reference point Z
Degrees
mm
mm or
degrees
mm
Y0 or C0
Z0
X0
(only for ShopTurn)
Peripheral surface C: The positions refer to the reference point:
Reference point Y or reference point length polar
Reference point Z
Cylinder diameter ∅
mm or de‐
grees
mm
mm
C0
Y0
Z0
X0
(only for ShopTurn)
Peripheral surface Y: The positions refer to the reference point:
Positioning angle for machining surface
Reference point Y
Reference point Z
Reference point X
Degrees
mm
mm
mm
∅ Diameter of pocket mm
Z1 Depth referred to Z0/X0 (inc) or pocket depth (abs) - (only for ∇, ∇∇∇ or ∇∇∇ edge) mm
DXY
● Maximum plane infeed
● Maximum plane infeed as a percentage of the milling cutter diameter
- (only for ∇ and ∇∇∇)
mm
%
DZ Maximum depth infeed – (only for ∇, ∇∇∇ or ∇∇∇ edge) mm
UXY Plane finishing allowance – (only for ∇, ∇∇∇ or ∇∇∇ edge) mm
UZ Depth finishing allowance – (only for ∇, ∇∇∇) mm
Programming technology functions (cycles)
10.4 Milling
Turning
Operating Manual, 06/2019, A5E44903486B AB 505
