Procedure
1. The part program or ShopTurn program to be processed has been cre‐
ated and you are in the editor.
2. Press the "Milling" softkey.
3. Press the "Groove" and "Circumferential groove" softkeys.
The "Circumferential Groove" input window opens.
Parameters in the "Input complete" mode
Parameters, G code program Parameters, ShopTurn program
Input
● Complete
PL Machining plane T Tool name
Milling direction D Cutting edge number
RP Retraction plane mm F Feedrate mm/min
mm/tooth
SC Safety clearance mm S / V Spindle speed or constant cutting
rate
rpm
m/min
F Feedrate *
Parameter Description Unit
Machining
surface
(only for Shop‐
Turn)
● Face C
● Face Y
● Peripheral surface C
● Peripheral surface Y
Position
(only for Shop‐
Turn)
● At the front (face)
● At the rear (face)
● Outside (peripheral surface)
● Inside (peripheral surface)
(only for Shop‐
Turn)
Clamp/release spindle (only for end face Y/peripheral surface Y)
The function must be set up by the machine manufacturer.
Programming technology functions (cycles)
10.4 Milling
Turning
536 Operating Manual, 06/2019, A5E44903486B AB
