Parameter Description Unit
Machining
● ∇ (roughing)
● ∇∇∇ (finishing)
● ∇∇∇ edge (edge finishing)
● Chamfering
FZ (only for G
code)
Depth infeed rate *
Circular pattern
● Full circle
The circumferential slots are positioned around a full circle. The distance from one
circumferential slot to the next circumferential slot is always the same and is
calculated by the control.
● Pitch circle
The circumferential slots are positioned around a pitch circle. The distance from one
circumferential slot to the next circumferential slot can be defined using angle α2.
X0
Y0
Z0
(only for G code)
The positions refer to the reference point:
Reference point X – (only for single position)
Reference point Y – (only for single position)
Reference point Z – (only for single position)
mm
mm
mm
X0 or L0
Y0 or C0
Z0
(only for Shop‐
Turn)
Face C: The positions refer to the reference point:
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
mm
mm or de‐
grees
mm
CP
X0 or L0
Y0 or C0
Z0
(only for Shop‐
Turn)
Face Y: The positions refer to the reference point:
Positioning angle for machining area – (only single position)
Angle CP does not have any effect on the machining position in relation to the workpiece.
It is only used to position the workpiece with the rotary axis C in such a way that machining
is possible on the machine.
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar - (only for single position)
Reference point Z - (only for single position)
Degrees
mm
mm or de‐
grees
mm
Y0 or C0
Z0
X0
(only for Shop‐
Turn)
Peripheral surface C: The positions refer to the reference point:
Reference point Y or reference point angle polar - (only for single position)
Reference point Z - (only for single position)
Cylinder diameter ∅ – (only for single position)
mm or de‐
grees
mm
mm
Programming technology functions (cycles)
10.4 Milling
Turning
Operating Manual, 06/2019, A5E44903486B AB 537
