Parameter Description
CP
X0 or L0
Y0 or C0
Z0
(only for ShopTurn)
Face Y: The positions refer to the reference point:
Positioning angle for machining area
Angle CP does not have any effect on the machining position in relation to the workpiece.
It is only used to position the workpiece with the rotary axis C in such a way that ma‐
chining is possible on the machine.
Reference point X or reference point length polar
Reference point Y or reference point angle polar
Reference point Z
Degrees
mm
mm or
degrees
mm
Y0 or C0
Z0
X0
(only for ShopTurn)
Peripheral surface C: The positions refer to the reference point:
Reference point Y or reference point angle polar
Reference point Z
Cylinder diameter ∅
mm or
degrees
mm
mm
C0
Y0
Z0
X0
(only for ShopTurn)
Peripheral surface Y: The positions refer to the reference point:
Positioning angle for machining surface
Reference point Y
Reference point Z
Reference point X
Degrees
mm
mm
mm
N Number of slots mm
R Radius of circumferential slot Degrees
α1 Opening angle of the slot Degrees
α2 Advance angle - (for pitch circle only) Degrees
W Slot width mm
Z1 Slot depth (abs) or depth relative to Z0 or X0 (inc) - (only for ∇ and ∇∇∇) mm
DZ Maximum depth infeed – (only for ∇ and ∇∇∇) mm
UXY Plane finishing allowance – (only for ∇ and ∇∇∇) mm
Positioning Positioning motion between the slots:
● Straight line:
Next position is approached linearly in rapid traverse.
● Circular:
Next position is approached along a circular path at the feedrate defined in the
machine data.
mm
FS Chamfer width for chamfering - (for chamfering only) mm
ZFS Insertion depth of tool tip (abs or inc) - (for chamfering only) mm
* Unit of feedrate as programmed before the cycle call
Programming technology functions (cycles)
10.4 Milling
Turning
540 Operating Manual, 06/2019, A5E44903486B AB
