Parameter Description
Machining
surface
(only for ShopTurn)
● Face C
● Face Y
● Peripheral surface C
● Peripheral surface Y
Position
(only for ShopTurn)
● At the front (face)
● At the rear (face)
● Outside (peripheral surface)
● Inside (peripheral surface)
(only for ShopTurn)
Clamp/release spindle (only for end face Y/peripheral surface Y)
The function must be set up by the machine manufacturer.
Machining
● ∇ (roughing)
● ∇∇∇ (finishing)
● ∇∇∇ edge (edge finishing)
● Chamfering
FZ (only for G code) Depth infeed rate *
Circular pattern
● Full circle
The circumferential slots are positioned around a full circle. The distance from one
circumferential slot to the next circumferential slot is always the same and is
calculated by the control.
● Pitch circle
The circumferential slots are positioned around a pitch circle. The distance from one
circumferential slot to the next circumferential slot can be defined using angle α2.
X0
Y0
Z0
(only for G code)
The positions refer to the reference point:
Reference point X
Reference point Y
Reference point Z
mm
mm
mm
X0 or L0
Y0 or C0
Z0
(only for ShopTurn)
Face C: The positions refer to the reference point:
Reference point X or reference point length polar
Reference point Y or reference point angle polar
Reference point Z
mm
mm or
degrees
mm
Programming technology functions (cycles)
10.4 Milling
Turning
Operating Manual, 06/2019, A5E44903486B AB 539
