Parameter Description Unit
FS Chamfer width for chamfering (inc) - (for chamfering only) mm
ZFS Insertion depth of tool tip (abs or inc) - (for chamfering only) mm
* Unit of feedrate as programmed before the cycle call
Parameters in the "Input simple" mode
G code program parameters ShopTurn program parameters
Input
● simple
T Tool name
RP Retraction plane mm D Cutting edge number
F Feedrate * F Feedrate mm/min
mm/rev
S / V Spindle speed or constant
cutting rate
rpm
m/min
Parameter Description
Machining
surface
(only for ShopTurn)
● Face C
● Face Y
● Peripheral surface C
● Peripheral surface Y
Position
(only for ShopTurn)
● At the front (face)
● At the rear (face)
● Outside (peripheral surface)
● Inside (peripheral surface)
(only for ShopTurn)
Clamp/release spindle (only for end face Y/peripheral surface Y)
The function must be set up by the machine manufacturer.
Machining
● ∇ (roughing)
● ∇∇∇ (pre-finishing)
● ∇∇∇ (finishing)
● ∇∇∇ base (base finishing)
● ∇∇∇ edge (edge finishing)
● Chamfering
Technology
● Vortex milling
The milling cutter performs circular motions along the length of the slot and back
again.
● Plunge cutting
Sequential drilling motion along the tool axis.
Programming technology functions (cycles)
