Parameter Description
Milling direction - (except plunge cutting)
● Climbing
● Conventional
● Climbing-conventional milling
X0
Y0
Z0
(only for G code)
The positions refer to the reference point:
Reference point X
Reference point Y
Reference point Z
mm
mm
mm
X0 or L0
Y0 or C0
Z0
(only for ShopTurn)
Face C: The positions refer to the reference point:
Reference point X or reference point length polar
Reference point Y or reference point angle polar
Reference point Z
mm
mm or
degrees
mm
CP
X0 or L0
Y0 or C0
Z0
(only for ShopTurn)
Face Y: The positions refer to the reference point:
Positioning angle for machining area
Angle CP does not have any effect on the machining position in relation to the workpiece.
It is only used to position the workpiece with the rotary axis C in such a way that ma‐
chining is possible on the machine.
Reference point X or reference point length polar
Reference point Y or reference point angle polar
Reference point Z
Degrees
mm
mm or
degrees
mm
Y0 or C0
Z0
X0
(only for ShopTurn)
Peripheral surface C: The positions refer to the reference point:
Reference point Y or reference point angle polar
Reference point Z
Cylinder diameter ∅
mm or
degrees
mm
mm
C0
Y0
Z0
X0
(only for ShopTurn)
Peripheral surface Y: The positions refer to the reference point:
Positioning angle for machining surface
Reference point Y
Reference point Z
Reference point X
Degrees
mm
mm
mm
W Slot width mm
L Slot length mm
Z1
(only for G code)
Slot depth (abs) or depth relative to Z0 (abs) – (only for ∇, ∇∇, ∇∇∇ and ∇∇∇ base) mm
Z1 or X1
(only for G code)
Slot depth (abs) or depth relative to Z0 or X0 (abs) – (only for ∇, ∇∇, ∇∇∇, ∇∇∇ base)
(Z1 for machining surface, face C/Y or X1 for peripheral surface C/Y)
mm
Programming technology functions (cycles)
10.4 Milling
Turning
550 Operating Manual, 06/2019, A5E44903486B AB
