Parameter Description Unit
ZV - only for work offset
write "yes"
● Offset Z = 0 (abs)
● Workpiece zero is offset in Z direction (inc, the sign is also evaluated)
The workpiece is re-clamped when switching between the main spindle and
counterspindle. The new work offset defines the position for machining at the
machine. However, the simulation must know by which amount the work
offset has shifted with respect to the workpiece, so that both sides of the
machining can be displayed.
mm
Z4P Machining position for special axis (abs.); machine coordinate system mm
Parameter Description Unit
Function, gripping Teaching in the park position and angular offset is possible
Gripping a blank
● With main spindle
The blank is gripped with the main spindle
● With counter-spindle
The blank is gripped with the counter-spindle
Work offset -
only for "with main spin‐
dle"
Buffer work offset:
● Basic reference
● G54
● G55
● G56
● G57
● ...
Coordinate
system
● MCS
The park position is specified in the machine coordinate system. Teaching in the
park position and angular offset is only possible in the machine coordinate
system.
● WCS
The park position is specified in the workpiece coordinate system.
XP Park position of tool in X direction (abs) mm
ZP Park position of tool in Z direction (abs) mm
Flush chuck Flush counter-spindle chuck
● Yes
● No
DIR Direction of rotation
● Spindle rotates clockwise
● Spindle rotates counter-clockwise
● Spindle does not rotate
S Spindle speed – (only when the spindle rotates) rev/min
α1 Angular offset Degrees
Z1 Transfer position (abs.)
ZR Position, feedrate reduction (abs or inc)
Position from which a reduced feedrate is used.
Programming technology functions (cycles)
10.7 Additional cycles and functions in ShopTurn
Turning
Operating Manual, 06/2019, A5E44903486B AB 655
