Parameter Description Unit
ZV (abs) - only for work
offset. write "yes"
Z value of the work offset. mm
ZV (inc) Workpiece zero is offset in Z direction (the sign is also evaluated)
The parameter is used to ensure that the correct display is shown in the simulation.
It has no influence on machining itself.
The workpiece is re-clamped when switching between the main spindle and coun‐
terspindle. The new work offset defines the position for machining at the machine.
However, the simulation must know by which amount the work offset has shifted
with respect to the workpiece, so that both sides of the machining can be displayed.
mm
See also
Program header (Page 300)
Program header with multi-channel data (Page 677)
Programming technology functions (cycles)
10.7 Additional cycles and functions in ShopTurn
Turning
Operating Manual, 06/2019, A5E44903486B AB 659
