● Blank
● Spindle chuck data (optional)
● Speed limitation
● If applicable data for the counter-spindle
● Counter-spindle with/without mirroring (for G code)
Machine manufacturer
If you are working with pure G code programming, it is possible that the parameter
screen "Multi-channel data" does not open.
Please observe the information provided by the machine manufacturer.
Parameter Description Unit
Measurement unit Selecting the measurement unit mm
inch
Main spindle
Work offset Selecting the work offset
Write to the
work offset
● Yes
Parameter ZV is displayed
● No
Parameter ZV is not displayed
ZV Z value of the work offset
For G54, the Z value is entered into the work offset.
Note:
Please observe the information provided by the machine manufacturer.
Blank
● Tube
● Cylinder
● Polygon
● Centered cuboid
XA Outside diameter ∅ – for tube and cylinder mm
XI Inside diameter (abs) or wall thickness (inc) – only for tube mm
ZA Initial dimension mm
ZI Final dimension (abs) or final dimension in relation to ZA (inc)
ZB Machining dimension (abs) or machining dimension in relation to ZA (inc) mm
N Number of edges – only for polygon
SW or L Width across flats or edge length – only for polygon mm
W Width of the blank - only for centered cuboid mm
L Length of the blank - only for centered cuboid mm
S Speed limitation of the main spindle rev/min
Multi-channel machining
11.2 Multi-channel support
Turning
Operating Manual, 06/2019, A5E44903486B AB 669
