Alignment angles β and γ

Alignment angles β and γ are required for turning with tool alignment.

;

=

˟

ˠ

β: Rotation around the Y axis (with the B axis)

γ: Rotation around the Z axis (with the tool spindle)

Working with a B axis (only 840D sl)

17.1 Lathes with B axis

Turning

876 Operating Manual, 06/2019, A5E44903486B AB
