Simrad ST90 Installation Manual

36
442703/B
Note
Iftheinstallationtrunkismanufacturedlocally,theinstallationshipyardisresponsible
forobtainingtheapprovalcerticatesfromtherelevantnationalregistry.
Relatedtopics
Scopeofsupply,page32
Mountingtheinstallationtrunk,page109
436691Installationtrunkdimensions,page435
207485Blindangedimensions(ø760mm),page438
Display
ThedisplayisnotastandardpartoftheST90delivery.Thisisacommercialitemthat
canbepurchasedlocally.
AnycommercialdisplaycanbeusedwiththeST90Fishndingsonar,providedthat
thedisplaymeetstheminimumrequirements.Thechosendisplaymustbedesignedfor
maritimeuse,anditmustmeettheminimumperformancespecications.Youmustalso
makesurethatthechosendisplaysupportsthevideoformatsprovidedbytheProcessor
Unit.
Wesuggestthatyoupurchasealargehigh-resolutiondisplay.
KongsbergMaritimemayprovideasuitabledisplay.
Display
PartnumberInthebox
335513
Display(19",1280x1024)
Powercable
Documentation
HattelandJH19T14
339785
Mountinghardware
383050
Display(24",1920x1080)
Powercable
Documentation
IsicDuraMONWSMD24
354265
Mountingbracket
417776
Display(24",1920x1080)
Powercable
Documentation
IsicDuraMONMD24Glass
419970
Mountingbracket
Relatedtopics
Scopeofsupply,page32
SimradST90InstallationManual
