Coursegyro

Inordertooperatecorrectly,theST90requiresinputfromacoursegyro.Acoursegyro

isnotapartoftheST90delivery.WhenacoursegyroisconnectedtotheST90,the

vessel’scurrentheadingcanbepresentedintheuserinterface.

Note

Withouttheinputfromacoursegyro,theST90willnotbeabletopresentcorrect

navigationalinformation.

Inmostcasesasuitablecoursegyroisalreadyinstalledonthevessel.Aglobal

positioningsystem(GPS)withacompatibleoutputformatcanalsobeused.

Thecoursegyrointerfacerequirementsare:

•Serialline:StandardNMEA0183datagramformats

•Ethernet(LAN)line:StandardNMEA0183datagramformats

Relatedtopics

Scopeofsupply,page32

SimradST90InstallationManual
