40
442703/B
Tip
IfyoualsowanttocontroltheST90fromthissecondarydisplaylocation,youcanaddan
extraOperatingPanel.
IfthedistancebetweentheProcessorUnitandyourseconddisplayisconsiderable,we
suggestthatyouuseKVM(KeyboardVideoMouse)technologytopreservethevideo
quality.
KongsbergMaritimemayprovideasuitabledisplay.Consultyourlocaldealeroragent
formoreinformation.
Relatedtopics
Scopeofsupply,page32
SecondaryOperatingPanel
AsecondaryOperatingPanelmaybeconnectedtotheST90ProcessorUnit.Thismay
beusefulinconjunctionwithaseconddisplayifyouwishtocontroltheST90fromtwo
differentlocationsonyourvessel.
ThecontrolsprovidedbytheOperatingPanelare
arrangedinlogicalfunctionalgroups.Thisoffers
youclearandeasyoperationwithfastaccesstokey
functionality.ThemajorityoftheST90functionscan
beaccessedusingthetrackballontheOperatingPanel
andthemenusystemshownintheST90presentation.
Youcanalsouseastandardcomputermousetocontrol
theST90.ThemousecanbeconnectedtoeithertheOperatingPanelordirectlyto
theProcessorUnit.
ItemPartnumberInthebox
SecondaryOperatingPanel
(Mk2)
442453
OperatingPanel
Ethernetcable
Mountinghardware
Tip
IfthedistancebetweentheProcessorUnitandyourseconddisplayisconsiderable,we
suggestthatyouuseKVM(KeyboardVideoMouse)technologytopreservethevideo
quality.
Relatedtopics
Scopeofsupply,page32
SettinguptheOperatingPanel(Mk2),page278
UsingasingleOperatingPaneltocontrolmorethanonesonar(Mk2),page320
UsingmorethanoneOperatingPaneltocontrolthesonar(Mk2),page324
