Simrad ST90 Installation Manual

442703/B
43
Gatevalve
PartnumberInthebox
DN500Manuallyoperatedgate
valve
–
Gatevalve
Mountinghardware
Documentation
DN500Hydraulicoperatedgate
valve
-
Gatevalve
HydraulicPowerPack
GateV alveControlUnit
Mountinghardware
Documentation
Mountingange
599–082973
Mountingange(forgatevalveDN500)
Transducerdock
427177
Transducerdock
Eachgatevalveisavailableinseveraldifferentversionswithdifferentcerticatesandsupplyvoltages.
Consultyourdealerformoreinformationaboutthegatevalvesavailable.
Note
Thegatevalveisplacedatthebottomofthetransducerdock.Itwillthenincreasethe
totalheightofthehullunitinstallation.
•Thehullunitlowersthetransducerdowntoaspecieddepthbelowtheship’ shull.
Thisdepthisdecreasedwiththephysicalheightofthegatevalve.Itisfurther
decreasedwiththeheightofthemountingange.
•TheST90allowsyoutodeneamiddlepositionforthetransducer .Whenyoudene
themiddleposition,youmusttakethetotalheightofthegatevalveandthemounting
angeintoconsideration.
TheST94HullUnitlowersthetransducerto2.1metresbelowthehull.Thishullunit
isabetterchoiceifagatevalveisused.
TechnicalinformationaboutthisunitisnotincludedinthisST90InstallationManual.
Refertotherelevantend-userdocumentationprovidedbythemanufacturer.
Relatedtopics
Scopeofsupply,page32
InstallingtheoptionalgatevalveDN500,page85
082973MountingangeDN500,page446
083045GatevalveinstallationDN500,page449
33498GatevalvedimensionsDN500,page451
37357GatevalvedimensionsDN500,page454
Extendedrange
TheST90canbesetupforextendedoperationalrange.
Duetointernationalregulations,sonarswithanoperationalrangeexceeding5000meters
cannotbeexportedtocertaincountrieswithoutanexportlicense.Forthisreasonthe
maximumrangeontheST90hasbeenlimitedto4500meters.Ifanexportlicenceis
obtained,therangeontheST90canbeextendedtoitsmaximumcapacity.
