UM0306 Controller area network (bxCAN)
325/519
194h
CAN_TDT1R TIME[15:0]
Reserved
TGT
Reserved
DLC[3:0]
Reset Value xxxxxxxxxxxxxxxx x xxxx
198h
CAN_TDL1R DATA3[7:0] DATA2[7:0] DATA1[7:0] DATA0[7:0]
Reset Value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
19Ch
CAN_TDH1R DATA7[7:0] DATA6[7:0] DATA5[7:0] DATA4[7:0]
Reset Value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
1A0h
CAN_TI2R STID[10:0] EXID[17:0]
IDE
RTR
TXRQ
Reset Value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx0
1A4h
CAN_TDT2R TIME[15:0]
Reserved
TGT
Reserved
DLC[3:0]
Reset Value xxxxxxxxxxxxxxxx x xxxx
1A8h
CAN_TDL2R DATA3[7:0] DATA2[7:0] DATA1[7:0] DATA0[7:0]
Reset Value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
1ACh
CAN_TDH2R DATA7[7:0] DATA6[7:0] DATA5[7:0] DATA4[7:0]
Reset Value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
1B0h
CAN_RI0R STID[10:0] EXID[17:0]
IDE
RTR
Reserved
Reset Value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
1B4h
CAN_RDT0R TIME[15:0] FMI[7:0]
Reserved
DLC[3:0]
Reset Value xxxxxxxxxxxxxxxxxxxxxxxx xxxx
1B8h
CAN_RDL0R DATA3[7:0] DATA2[7:0] DATA1[7:0] DATA0[7:0]
Reset Value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
1BCh
CAN_RDH0R DATA7[7:0] DATA6[7:0] DATA5[7:0] DATA4[7:0]
Reset Value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
1C0h
CAN_RI1R STID[10:0] EXID[17:0]
IDE
RTR
Reserved
Reset Value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
1C4h
CAN_RDT1R TIME[15:0] FMI[7:0]
Reserved
DLC[3:0]
Reset Value xxxxxxxxxxxxxxxxxxxxxxxx xxxx
1C8h
CAN_RDL1R DATA3[7:0] DATA2[7:0] DATA1[7:0] DATA0[7:0]
Reset Value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
1CCh
CAN_RDH1R DATA7[7:0] DATA6[7:0] DATA5[7:0] DATA4[7:0]
Reset Value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
1D0h-1FFh
Reserved
Table 44. bxCAN - register map and reset values (continued)
