Controller area network (bxCAN) UM0306
326/519
200h
CAN_FMR
Reserved
FINIT
Reset Value 1
204h
CAN_FM0R
Reserved
FBM[13:0]
Reset Value 00000000000000
208h
Reserved
20Ch
CAN_FS0R
Reserved
FSC[13:0]
Reset Value 00000000000000
210h
Reserved
214h
CAN_FFA0R
Reserved
FFA[13:0]
Reset Value 00000000000000
218h
Reserved
21Ch
CAN_FA0R
Reserved
FACT[13:0]
Reset Value 00000000000000
220h
Reserved
224-23Fh
Reserved
240h
CAN_F0R0 FB[31:0]
Reset Value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
244h
CAN_F0R1 FB[31:0]
Reset Value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
248h
CAN_F1R0 FB[31:0]
Reset Value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
24Ch
CAN_F1R1 FB[31:0]
Reset Value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
.
.
.
.
.
.
.
.
.
.
.
.
2A8h
CAN_F13R0 FB[31:0]
Reset Value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
2ACh
CAN_F13R1 FB[31:0]
Reset Value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
Table 44. bxCAN - register map and reset values (continued)
Offset Register
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
