UM0306 Inter-integrated circuit (I2C) interface

355/519

Bit 1

BUSY: Bus Busy

0: No communication on the bus

1: Communication ongoing on the bus

– Set by hardware on detection of SDA or SCL low

– cleared by hardware on detection of a Stop condition.

It indicates a communication in progress on the bus. This information is still

updated when the interface is disabled (PE=0).

Bit 0

MSL: Master/Slave

0: Slave Mode

1: Master Mode

– Set by hardware as soon as the interface is in Master mode (SB=1).

– Cleared by hardware after detecting a Stop condition on the bus or a loss of

arbitration (ARLO=1), or by hardware when PE=0.
