UM0306 Universal synchronous asynchronous receiver transmitter (USART)
409/519
17.4.2 Data register (USART_DR)
Address Offset: 04h
Reset Value: Undefined
17.4.3 Baud rate register (USART_BRR)
Note: The baud counters stop counting if the TE or RE bits are disabled respectively.
Address Offset: 08h
Reset Value: 0000h
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
1514131211109876543210
Reserved DR[8:0]
rw rw rw rw rw rw rw rw rw
Bits 31:9 Reserved, forced by hardware to 0.
Bits 8:0
DR[8:0]: Data value.
Contains the Received or Transmitted data character, depending on whether it is
read from or written to.
The Data register performs a double function (read and write) since it is
composed of two registers, one for transmission (TDR) and one for reception
(RDR)
The TDR register provides the parallel interface between the internal bus and the
output shift register (see Figure 1).
The RDR register provides the parallel interface between the input shift register
and the internal bus.
When transmitting with the parity enabled (PCE bit set to 1 in the USART_CR1
register), the value written in the MSB (bit 7 or bit 8 depending on the data length)
has no effect because it is replaced by the parity.
When receiving with the parity enabled, the value read in the MSB bit is the
received parity bit.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
1514131211109876543210
DIV_Mantissa[11:0] DIV_Fraction[3:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:16 Reserved, forced by hardware to 0.
