USB full speed device interface (USB) UM0306
436/519
USB interrupt status register ()
Address Offset: 44h
Reset Value: 0000 0000 0000 0000 (0000h)
This register contains the status of all the interrupt sources allowing application software to
determine, which events caused an interrupt request.
The upper part of this register contains single bits, each of them representing a specific
event. These bits are set by the hardware when the related event occurs; if the
corresponding bit in the register is set, a generic interrupt request is generated. The
interrupt routine, examining each bit, will perform all necessary actions, and finally it will
clear the serviced bits. If any of them is not cleared, the interrupt is considered to be still
pending, and the interrupt line will be kept high again. If several bits are set simultaneously,
only a single interrupt will be generated.
Endpoint transaction completion can be handled in a different way to reduce interrupt
response latency. The CTR bit is set by the hardware as soon as an endpoint successfully
completes a transaction, generating a generic interrupt request if the corresponding bit in is
set. An endpoint dedicated interrupt condition is activated independently from the CTRM bit
in the register. Both interrupt conditions remain active until software clears the pending bit in
the corresponding register (the CTR bit is actually a read only bit). USB PeripheralFor
endpoint-related interrupts, the software can use the Direction of Transaction (DIR) and
EP_ID read-only bits to identify, which endpoint made the last interrupt request and called
the corresponding interrupt service routine.
The user can choose the relative priority of simultaneously pending events by specifying the
order in which software checks bits in an interrupt service routine. Only the bits related to
events, which are serviced, are cleared. At the end of the service routine, another interrupt
will be requested, to service the remaining conditions.
To avoid spurious clearing of some bits, it is recommended to clear them with a load
instruction where all bits which must not be altered are written with 1, and all bits to be
cleared are written with ‘0’ (these bits can only be cleared by software). Read-modify-write
cycles should be avoided because between the read and the write operations another bit
could be set by the hardware and the next write will clear it before the microprocessor has
the time to serve the event.
Bit 1
PDWN: Power down
This bit is used to completely switch off all USB-related analog parts if it is required to
completely disable the USB Peripheral for any reason. When this bit is set, the USB
Peripheral is disconnected from the transceivers and it cannot be used.
0: Exit Power Down.
1: Enter Power down mode.
Bit 0
FRES: Force USB Reset
0: Clear USB reset.
1: Force a reset of the USB Peripheral, exactly like a RESET signalling on the USB.
The USB Peripheral is held in RESET state until software clears this bit. A “USB-
RESET” interrupt is generated, if enabled.
1514131211109876543210
CTR
PMA
OVR
ERR WKUP SUSP RESET SOF ESOF DIR EP_ID[3:0]
rrcrcrcrcrcrcrc rrrrr
