UM0306 USB full speed device interface (USB)
437/519
The following describes each bit in detail:
Bit 15
CTR: Correct Transfer
This bit is set by the hardware to indicate that an endpoint has successfully completed a
transaction; using DIR and EP_ID bits software can determine which endpoint
requested the interrupt. This bit is read-only.
Bit 14
PMAOVR: Packet Memory Area Over / Underrun
This bit is set if the microcontroller has not been able to respond in time to an USB
memory request. The USB Peripheral handles this event in the following way: During
reception an ACK handshake packet is not sent, during transmission a bit-stuff error is
forced on the transmitted stream; in both cases the host will retry the transaction. The
PMAOVR interrupt should never occur during normal operations. Since the failed
transaction is retried by the host, the application software has the chance to speed-up
device operations during this interrupt handling, to be ready for the next transaction
retry; however this does not happen during Isochronous transfers (no isochronous
transaction is anyway retried) leading to a loss of data in this case. This bit is read/write
but only ‘0’ can be written and writing ‘1’ has no effect.
Bit 13
ERR: Error
This flag is set whenever one of the errors listed below has occurred:
NANS: No ANSwer. The timeout for a host response has expired.
CRC: Cyclic Redundancy Check error. One of the received CRCs, either in the token or
in the data, was wrong.
BST: Bit Stuffing error. A bit stuffing error was detected anywhere in the PID, data,
and/or CRC.
FVIO: Framing format Violation. A non-standard frame was received (EOP not in the
right place, wrong token sequence, etc.).
The USB software can usually ignore errors, since the USB Peripheral and the PC host
manage retransmission in case of errors in a fully transparent way. This interrupt can be
useful during the software development phase, or to monitor the quality of transmission
over the USB bus, to flag possible problems to the user (e.g. loose connector, too noisy
environment, broken conductor in the USB cable and so on). This bit is read/write but
only ‘0’ can be written and writing ‘1’ has no effect.
Bit 12
WKUP: Wake up
This bit is set to 1 by the hardware when, during suspend mode, activity is detected that
wakes up the USB Peripheral. This event asynchronously clears the LP_MODE bit in the
CTLR register and activates the USB_WAKEUP line, which can be used to notify the
rest of the device (e.g. wake-up unit) about the start of the resume process. This bit is
read/write but only ‘0’ can be written and writing ‘1’ has no effect.
Bit 11
SUSP: Suspend mode request
This bit is set by the hardware when no traffic has been received for 3mS, indicating a
suspend mode request from the USB bus. The suspend condition check is enabled
immediately after any USB reset and it is disabled by the hardware when the suspend
mode is active (FSUSP=1) until the end of resume sequence. This bit is read/write but
only ‘0’ can be written and writing ‘1’ has no effect.
