USB full speed device interface (USB) UM0306
438/519
Bit 10
RESET: USB RESET request
Set when the USB Peripheral detects an active USB RESET signal at its inputs. The
USB Peripheral, in response to a RESET, just resets its internal protocol state machine,
generating an interrupt if RESETM enable bit in the register is set. Reception and
transmission are disabled until the RESET bit is cleared. All configuration registers do
not reset: the microcontroller must explicitly clear these registers (this is to ensure that
the RESET interrupt can be safely delivered, and any transaction immediately followed
by a RESET can be completed). The function address and endpoint registers are reset
by an USB reset event.
This bit is read/write but only ‘0’ can be written and writing ‘1’ has no effect.
Bit 9
SOF: Start Of Frame
This bit signals the beginning of a new USB frame and it is set when a SOF packet
arrives through the USB bus. The interrupt service routine may monitor the SOF events
to have a 1mS synchronization event to the USB host and to safely read the register
which is updated at the SOF packet reception (this could be useful for isochronous
applications). This bit is read/write but only ‘0’ can be written and writing ‘1’ has no
effect.
Bit 8
ESOF: Expected Start Of Frame
This bit is set by the hardware when an SOF packet is expected but not received. The
host sends an SOF packet each mS, but if the hub does not receive it properly, the
Timer issues this interrupt. If three consecutive ESOF interrupts are generated (i.e. three
SOF packets are lost) without any traffic occurring in between, a SUSP interrupt is
generated. This bit is set even when the missing SOF packets occur while the Timer is
not yet locked. This bit is read/write but only ‘0’ can be written and writing ‘1’ has no
effect.
Bit 4
DIR: Direction of transaction.
This bit is written by the hardware according to the direction of the successful
transaction, which generated the interrupt request.
If DIR bit=0, CTR_TX bit is set in the register related to the interrupting endpoint. The
interrupting transaction is of IN type (data transmitted by the USB Peripheral to the host
PC).
If DIR bit=1, CTR_RX bit or both CTR_TX/CTR_RX are set in the register related to the
interrupting endpoint. The interrupting transaction is of OUT type (data received by the
USB Peripheral from the host PC) or two pending transactions are waiting to be
processed.
This information can be used by the application software to access the bits related to
the triggering transaction since it represents the direction having the interrupt pending.
This bit is read-only.
Bits 3:0
EP_ID[3:0]: Endpoint Identifier.
These bits are written by the hardware according to the endpoint number, which
generated the interrupt request. If several endpoint transactions are pending, the
hardware writes the endpoint identifier related to the endpoint having the highest priority
defined in the following way: Two endpoint sets are defined, in order of priority:
Isochronous and double-buffered bulk endpoints are considered first and then the other
endpoints are examined. If more than one endpoint from the same set is requesting an
interrupt, the EP_ID bits in register are assigned according to the lowest requesting
endpoint register, EP0R having the highest priority followed by EP1R and so on. The
application software can assign a register to each endpoint according to this priority
scheme, so as to order the concurring endpoint requests in a suitable way. These bits
are read only.
